Renogy 280W 24V Mono Panel

Renogy 280W 24V Mono Panel

349.95

The Renogy 280 Watt 24 Volt Monocrystallne Solar Panel is the first step to converting your house from an energy dependant home to an energy producing location. Primarily used for residential purposes, the 280 Watt Panel can also be used in on-grid applications that require a multi-panel solar array suitable for cabins, sheds, and commercial buildings.

Minimum Purchase: 2 Units

Quantity:
Add To Cart
Features

Reliable

  • EL tested solar modules; no hot-spot heating guaranteed.
  • Authorized UL 1703 photovoltaic modules and panels.
  • Guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa).
  • Perfect for residential and commercial rooftop systems to decrease your electrical bill, or for large off-grid systems as well.

Durable

  • Guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa).
  • Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades.
  • Anti-reflective, high transparency, low iron-tempered glass with enhanced stiffness and impact resistance.
  • IP67 rated junction box provides complete protection against environmental particles and low pressure water jets.

Versatile

  • Can be used for many different applications; ideal for residential and commercial rooftop systems.
  • Ground mount compatible.
  • Compatible with on-grid and off-grid inverters.

Installation Ready

  • Pre-drilled holes on the back of the panel allow for fast mounting and securing.
  • Pre-drilled holes included for grounding.
  • Ideal with large rail mounts for extra support and security.
Specs

Built-in Components

Renogy 280 Watt Monocrystalline Solar Panel
Panel Leads (Pair): 12AWG
IP67 Rated waterproof junction box
IP67 Rated waterproof MC4 connectors

Specifications

Maximum Power: 280W
Optimum Operating Voltage (Vmp): 31V
Optimum Operating Current (Imp): 9.03A
Weight: 40lbs
Maximum System Voltage: 1000V DC (UL)
Open-Circuit Voltage (Voc): 38.20V
Short-Circuit Current (Isc): 9.39A
Dimensions: 64.5 x 39 x 1.6 inches

Warranty

25-year power output warranty: 5 year/95% efficiency rate, 10 year/90% efficiency rate, 25-year/80% efficiency rate
5-year material and workmanship warranty
Accessories: 1-year material warranty

Manuals
Videos

Coming Soon

Shipping

Renogy Solar Panels ship within two business days from Ontario, CA.
